Mentalab Explore Pro
Third generation mobile EEG, designed for research and industry.
Exceptional precision at an unparalleled size.
8 channels
16 / 32 channels
configurable
channels
hours
battery life
grams
weight
dimensional
motion tracking
meters operating
range
Explore Pro is a wearable EEG amplifier, designed to work in any experimental set-up.
Powerful amplifier
We know that reliable high-quality data is key, so we made it easy to collect.
| Up to 32 channels plus 9D motion sensor |
| 1 kHz streaming, 2 kHz offline recording |
| True DC ExG with 24-bit resolution |
| Wired and wireless triggers (with ms accuracy) |
Adaptable service
Don’t be restricted in your research.
| Modular design for customisable set-ups |
| Open-source APIs in NeuroPype, Android, iOS, MATLAB, Python, BrainFlow |
| Expert consultants |
Mobile products
Attach anywhere, feel nothing.
| Amplifier weighs 27 g |
| Stream wireless data over 10 meters |
| Record up to 12 hours in one session |
| Enjoy remote updates |
Versatile applications across disciplines
Explore Pro is designed to adapt. Our hardware is used across a range of research fields.
Cognitive neuroscience
Use EEG, EOG, ECG, and EMG to study cognitive function and its neural underpinnings. Our wearable EEG amplifier gives easy access to bio-signal data.
Brain computer interfaces
Translate EEG signals into actionable commands in real-time. Leverage our open-source software and raw-data stream to create advanced data pipelines.
Neurodevelopment
Investigate brain development with an amplifier that doesn’t disturb children. Choose a children’s cap and soft electrodes for an optimal set-up.
Sleep research
Let users sleep whilst recording their brain activity. Record EEG and ECG simultaneously using an amplifier that won’t wake up participants.
Sports performance
Use neurophysiology to understand when and where people perform at their best. Explore Pro is light enough to ignore and powerful enough to measure performance bio-signals.
Engineering art
Apply bio-signals to artistic and engineering projects where signal quality is important and usability critical. Explore Pro helps you collect bio-signals in minutes.
Electrodes and caps
Mix and match your set-up with our high-quality electrodes and caps.
Customize your electrodes
One of Mentalab’s key design principles is adaptability. With any purchase of an Explore Pro system, you can customize your cable tree.
UL-09
Standard configuration
Each cable set consists of 8, 16, or 32 electrodes and one unipolar reference electrode. You decide what type of electrode each channel uses.
| model | type |
|---|---|
| UL-09 | 8-channel system |
| UL-17 | 16-channel system |
| UL-33 | 32-channel system |
1MMEXT
Additional customization
For easy multi-modal setups, attach a mini touch-proof connector to multiple channels and connect individual leads of any length and type.
| model | type |
|---|---|
| 1MMEXT | Mini touch-proof connector |
| EAR-CLP | Ear-clip reference cable |
| INDLD | Individual channel lead |
Electrode types
All of our electrodes are coated in soft Ag/AgCl, combining excellent comfort with optimal data acquisition. Choose from wet and dry, flat and brush electrodes.
HRG
Wet electrode cables
Wet electrode cables have integrated, sintered, Ag/AgCl electrodes that cannot be removed.
| model | type |
|---|---|
| HRG | Ring electrode cable |
| HRM | Multitrode electrode cable |
HRBHRC
Dry electrode cables
Dry electrode cables terminate in connectors. You can then attach and remove dry electrodes to and from these connectors. Mentalab dry electrodes are Ag/AgCl-coated conductive polymer electrodes. They require no conductive gel, are soft to the touch, and reusable.
| model | type |
|---|---|
| HRB | Button connector cable |
| HRC | Alligator clip connector cable |
HRM
Electrodes
| model | type | |
|---|---|---|
| HRM | Multitrode electrode | wet |
| FLT | Flat electrode | dry |
| FLT-XL | Flat electrode, extra thick | dry |
| BRSH | Brush electrode | dry |
| BRSH-XL | Brush electrode, extra long | dry |
| STCKPL | Stick & Peel electrodes (x20) | dry |
Caps
Our caps are made from stretchy neoprene. They come in six sizes so that your participants can enjoy the most comfortable experience possible.
Cap sizes
| model | size | head circumference |
|---|---|---|
| CAP-XS | XS | 36-42 cm / 14-16.5 inch |
| CAP-SXS | S/XS | 39-45 cm / 15-17.7 inch |
| CAP-S | S | 42-48 cm / 16.5-19 inch |
| CAP-M | M | 48-54 cm / 19-21 inch |
| CAP-L | L | 54-60 cm / 21-23.5 inch |
| CAP-XL | XL | 60-66 cm / 23.5-26 inch |
Fabric caps with embedded electrodes are available upon request.
